Hangzhou Coditeck Digital Co.,Ltd
| Enclosure | Die-cast based print mechanism/Metal cover with large clear media view window |
|---|---|
| Physical dimension |
248 mm (W) x 274 mm (H) x 436 mm (D) 9.76” (W) x 10.79” (H) x 17.17” (D) |
| Weight | 9 kg (19.84 lbs) |
| Processor | 32-bit RISC CPU |
| Memory |
128 MB Flash memory 128 MB SDRAM |
| Interface |
RS-232 USB 2.0 Internal Ethernet, 10/100 Mbps USB host, for scanner or PC keyboard GPIO (dealer option) Internal Bluetooth 4.2 MFi (factory option) Slot-in 802.11 a/b/g/n wireless (dealer option) |
| Power |
Internal universal switching power supply Input: AC 100~240V, 3.0A, 50~60Hz Output: DC 24V, 8.33A, 200W |
| Operation switch, button | 2 buttons (Pause, Feed) |
| Sensors |
Gap transmissive sensor (position adjustable) Black mark reflective sensor (position adjustable) Ribbon end sensor Ribbon encoder sensor Head open sensor |
| Printer language | TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL) |
| Environment condition |
Operation: 5 ~ 40°C, 25 ~ 85% non-condensing Storage: -40 ~ 60°C, 10 ~ 90% non-condensing |
| Enclosure | Die-cast based print mechanism/Metal cover with large clear media view window |
|---|---|
| Physical dimension |
248 mm (W) x 274 mm (H) x 436 mm (D) 9.76” (W) x 10.79” (H) x 17.17” (D) |
| Weight | 9 kg (19.84 lbs) |
| Processor | 32-bit RISC CPU |
| Memory |
128 MB Flash memory 128 MB SDRAM |
| Interface |
RS-232 USB 2.0 Internal Ethernet, 10/100 Mbps USB host, for scanner or PC keyboard GPIO (dealer option) Internal Bluetooth 4.2 MFi (factory option) Slot-in 802.11 a/b/g/n wireless (dealer option) |
| Power |
Internal universal switching power supply Input: AC 100~240V, 3.0A, 50~60Hz Output: DC 24V, 8.33A, 200W |
| Operation switch, button | 2 buttons (Pause, Feed) |
| Sensors |
Gap transmissive sensor (position adjustable) Black mark reflective sensor (position adjustable) Ribbon end sensor Ribbon encoder sensor Head open sensor |
| Printer language | TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL) |
| Environment condition |
Operation: 5 ~ 40°C, 25 ~ 85% non-condensing Storage: -40 ~ 60°C, 10 ~ 90% non-condensing |
