BrandDatalogic
Product LineDatalogic PowerScan
ModelPD9531-K2
ManufacturerDatalogic
Product Information
Scanner FunctionalityBarcode scanner
FeaturesDatalogic Three Green Lights (3GL), Image capturing, Rugged, Triggered
KitKit
Max Coverage Angle40
OK NotificationBeeper, LED indicator
Packaged Quantity1
TTL DecodingDecoded
Dimensions & Weight
Height8.3 inch
Weight11.64 ounce
Width2.9 inch
Depth4.3 inch
Technical Information
Drop Specification6.5 ft
Form FactorHandheld
Image Sensor Type2D imager
InterfaceRS-232
Light Source Wave Length630-680 nm
Max Operating Temperature122 degree Fahrenheit
Min Operating Temperature-4 degree Fahrenheit
Min Scan Field0.79 inch
Minimum Bar Width4 milli-inch
Operating Humidity0 - 95% (non-condensing)
Print Contrast Signal (PCS)15%
Scanning Distance33.5 inch
Skew (Degrees)40
