Zebra 105SL INDUSTRIAL PRINTER 300dpi

The Zebra 105SL 300dpi Industrial Barcode Printer combines enhanced storage and handling capabilities with a durable, reliable metal construction. It is an excellent product with multiple functions and excellent value for money. Its high stability, high productivity and fast printing make you more convenient and efficient.
Zebra 105SL 300dpi Industrial Barcode Printer adds the following features:
‧Dual 32 Bit Processer, RISC (Reduced Instruction Set), fast operation speed, and CISC (Complex Instruction Set), high compatibility; Zebra 105SL 300dpi integrates the advantages of two types of arithmetic units, so the calculation efficiency is higher
‧Flash Firmware update version is more convenient
‧Standard DRAM increased to 4 MB (2MB User available)
‧Standard 4MB Flash Memory(750K User available)
‧Standard LCD Display
‧Serial & Parallel dual interface coexistence
‧Printing speed increased to 8"/sec
Zebra 105SL 300dpi industrial barcode printer is very suitable for label printing such as product labeling, asset management, document tracking, material management, incoming and outgoing goods management, and inventory due to its high stability and low price.

grade
Industrial type

resolution
300dpi

Memory
6 MB SDRAM, 4MB FLSH 32 MB (PCMCIA card optional)

print mode
thermal thermal transfer

print speed
8ips

print width
4 inches

communication interface
Centronics® RS-232, RS-422* and RS-485* serial ports; IEEE 1284 bidirectional parallel ports

paper sensor
Transmissive, reflective (optional)

built-in font
Standard fonts: 7 dot matrix characters, 1 smooth scaling (CG Triumvirate™ Bold Condensed) Character sets: IBM® code body page 850 International character sets Optional European and Asian font sets include Agfa Monotype Corp. Company's UFST®

Instruction Set
ZPL, ZPL II

Dimensions
495mm(L)*283mm(W)*394mm(H)

weight
25 kg

Ribbon length
450M

Ribbon width
2~11.4 cm

Ribbon shaft
1 inch

paper width
2~11.5 cm

paper thickness
0.076~0.305 mm

paper axis
3 inches

Recommended paper roll capacity
100M

1D barcode
Codabar Code 11 Code 39 Code 93 EAN-13 EAN-8 Interleaved 2-of-5 Industrial 2-of-5 Logmars MSI Planet Code Plessey Postnet Standard 2-of-5 UPC and EAN 2 or 5 digit extensions UPC-E UPC- A Code 128 with subsets A/B/C and UCC case codes ISBT-128

QR code
Codablock Code 49 Data Matrix MaxiCode PDF417 QR Code RSS / GS1 DataBar family (12 barcodes) TLC 39 MicroPDF Aztec

Safety certification
UL 1950; CISPR 22 (Class B); CSA 950; IEC 950; 801-2, -3 and -4 Standards; Canadian Doc. (Class A); FCC (Class A); CE Regulations
